Drilling Head Units SD7-130M
- Description
Description
| Model | SD7-130M |
| Drilling Capacity (S45C) | ø20mm |
| Max. Stroke | 130mm |
| Max. RPM | 2500RPM |
| Propel Pressure | 油壓 (H) 20~30kg/cm² |
| Cylinder Diameter | 前進 (F) 37cm² 後退 (B) 15.9cm² |
| Horsepower, 3 Phase | 1HP, 220V/380V |
| Transmission Belt | A2xø100, 8Mx40Tx50W |
| Net Weight | 57kg |
| Spindle Bearing | 6004Z, 32004 6005Z, 32005 |
| Pulley Bearing | 6008Z, 51208 |
| Front Cover Seal | TC60x70x10 |
| Piston O-ring | AP-65×2, AG-35×1, TC32-52×10 |
| Front Cover O-ring | AP-60×2, AG-70×1, AG-80×1 |
| Back Cover O-ring | AP-30×2, AG-70×1, AG-80×1 |
